1) The commercial vehicle tracking systems support LTE CAT M1 network standard
2) GPS+BD+QZSS positioning, support A-GPS fast positioning
3) LTE antenna and GPS antenna built-in
4) IP67 waterproof rating
5) Support one button, which can be defined as event function
6) Affordable GPS semi truck trackers for tractor price
|Indicator||1: Power indicator: green|
2: Positioning status indicator: blue
3: CAT M1 status indicator: orange
|CPU||ARM 32BIT Cortex-M4 CPU ( GD32F303RE ) , 120Mhz Max frequency,|
|GNSS positioning module||GNSS module :|
Support GPS, GLONASS, BD&QZSS; Support A-GPS function
CEP50: 2.5 meters (open field)
Capture Sensitivity: -148 dBm
Tracking Sensitivity: -162 dBm
Cold start: 32S typical(open sky) Warm start: 1S
|LTE module||Built-in Quectel BG95-M3 （CATM)|
AT&T/Verizon/T-Mobile/Sprint (North America)
|G-SENSOR||builtin 3-axis acceleration sensor|
|Button||1button (*example: It can be defined as SOS button)|
|Power||2 power supply methods:|
1. USB-C 5V power supply
2. 9-36v power input (*through extension 10-PIN interface)
|Interface||1xUSB-C type interface (for power supply)|
1x10-PIN extended function interface
1xNANO SIM card slot
|Installation method||3M glue installation|
|Working temperature||-30℃~+70℃ Humility:0%~90%RH|
Real-Time Tracking: The PB001 LTE Waterproof Commercial Truck GPS Tracker provides real-time location updates of commercial vehicles. This feature is crucial for businesses to monitor their fleet’s whereabouts and ensure efficient operations.
LTE Connectivity: The commercial truck tracking devices are equipped with LTE connectivity, enabling them to deliver real-time tracking information. This feature is particularly beneficial for logistics companies for better route planning and timely deliveries.
Waterproof Design: The GPS tracking device for commercial trucks is waterproof, making it resilient in all weather conditions. The commercial truck tracking system can provide accurate tracking information even in heavy rain or snow, allowing businesses to monitor their vehicles continuously.
Vehicle Behavior Monitoring: The PB001 LTE Waterproof Commercial Truck GPS Tracker can monitor various vehicle metrics such as speed, fuel consumption, and engine status. This data can help identify potential vehicle issues early, enabling businesses to address them promptly.
Safety Alerts: The semi-truck and tractor tracking device can send alerts if a vehicle leaves a designated area or detects unusual behavior like excessive speed or sudden braking. This feature helps businesses ensure the safety of their drivers and vehicles.
Geo-Fencing: This function allows businesses to set up virtual boundaries for their vehicles. If a vehicle crosses these boundaries, the semi-truck tracker sends an alert, helping to prevent unauthorized use or theft.
Long Battery Life: The PB001 LTE Waterproof Commercial Truck GPS Tracker has a long battery life, ensuring continuous tracking without frequent recharging.
Easy Installation: The commercial truck GPS tracker is designed for easy installation, making it convenient for businesses to equip their entire fleet.
User-Friendly Interface: The semi-truck tracking device comes with a user-friendly interface, making it easy for businesses to monitor and manage their fleet.
Robust Construction: The PB001 Commercial Truck GPS Tracker is built to last, ensuring reliable performance even in harsh conditions.
The frequency of recharging the battery of the PB001 LTE Commercial Truck GPS Tracker depends on several factors. Here’s a breakdown:
Usage: The frequency of use directly impacts the battery life. If the semi-truck tracking device is used continuously, it will require more frequent recharging.
Tracking Interval: The frequency of location updates also affects battery life. If the semi-truck tracking device is set to provide real-time updates every few seconds, the battery will drain faster than if updates are set for every few minutes or hours.
Network Connectivity: The strength of the LTE network can also influence battery life. If the commercial truck tracking system is constantly searching for a signal due to poor network coverage, it can drain the battery faster.
Weather Conditions: Extreme weather conditions can affect battery performance. Cold temperatures, in particular, can cause the battery to drain faster.
Device Settings: Certain settings, like high screen brightness or volume, can also consume more battery power.
Age of the Device: Over time, the battery’s capacity to hold a charge diminishes, leading to more frequent recharging.
While it’s difficult to provide an exact frequency without knowing these specifics, a good rule of thumb for many vehicle trackers is to recharge them at least once a week under normal usage conditions. However, the PB001 LTE Waterproof Commercial Vehicle Tracker is designed with a long-lasting battery, reducing the need for frequent recharging and ensuring reliable tracking performance. Always refer to the manufacturer’s instructions for specific guidance on charging frequency.
Accessing the data collected by GPS commercial truck tracking devices like the PB001 LTE Waterproof Commercial Vehicle Tracker is a straightforward process. Here’s a step-by-step guide:
Installation: The first step is to install the GPS tracking devices for commercial trucks in the vehicle. This device will collect data such as location, speed, and direction.
Data Transmission: The commercial truck tracker uses LTE connectivity to transmit this data to a central server. The frequency of data transmission can be set according to your needs, from real-time updates to intervals of a few minutes or hours.
Accessing the Server: The data collected by the GPS commercial vehicle tracker is stored on a secure server. To access this data, you need to log into the server using a computer or a mobile device. This usually requires a username and password provided by the GPS tracking service provider.
Using the Interface: Once logged in, you can view the data through a user-friendly interface. This typically includes a map showing the real-time location of your vehicles, as well as historical data such as travel routes and stop times.
Analyzing the Data: The interface also allows you to analyze the data. You can generate reports on various metrics such as fuel consumption, driver behavior, and vehicle performance. This can help you identify areas for improvement and make informed decisions to enhance operational efficiency.
Alerts: The GPS commercial truck tracking system can also send alerts based on certain parameters, such as when a vehicle leaves a designated area or exceeds a certain speed. These alerts can be received via email or SMS, helping you to promptly address any issues.
